Productomschrijving
204L - 121 CM
| Gewicht (Kg) | 31.5 |
|---|---|
| Jaarlijks verbruik (kWh) | 129 |
| ArtRef | LBI2201 |
| AsogemID | 115469 |
| MPN | 7515720006 |
| Merk | BEKO |
| Soort | Koelkast integreerbaar zonder vriesvak |
| ArtEAN | 8690842346231 |
EXPLODED VIEWS
ONDERDELEN
| Onderdeelnr | Nr | Omschrijving | Prijscode | Aantal | Alternatief onderdeel | |||
|---|---|---|---|---|---|---|---|---|
| 4094880200 | 0 | INTERIOR LIGHT SWITCH | 6 | 1 | Meer info | |||
| 4306470900 | 3 | THERMOSTAT KNOB PRINTED ARC P1 | 4 | 1 | Meer info | |||
| 9002755085 | 4 | THERMOSTAT (K 59 L2724) | 17 | 1 | Meer info | |||
| 4307200300 | 13 | HINGE GROUP.(LOWER_BUILT-IN) | 7 | 1 | Meer info | |||
| 4307200400 | 14 | HINGE GROUP.(UPPER_BUILT-IN) | 6 | 1 | Meer info | |||
| 4210140100 | 20 | AIR GRILLE BUILT IN | 6 | 1 | Meer info | |||
| 4361194700 | 30 | COMPRESSOR JIAXIPERA TG1110Y(AL) | 40 | 1 | Meer info | |||
| 4346041200 | 39 | COMBO UNIT(JIAXPERA) | 12 | 1 | Meer info | |||
| 4317500300 | 53 | CONDENSER ASSY | 19 | 1 | Meer info | |||
| 4232090100 | 80 | COMPRESSOR TRAVERSE LIFTING PART | 1 | 2 | Meer info | |||
| 4623980100 | 132 | WATER COLECTOR TRAY JIAXIPERA | 13 | 1 | Meer info | |||
| 4846070100 | 132 | EVAPORATING PAN _ EMBRACO MTS | 10 | 0 | Meer info | |||
| 4629950100 | 135 | MIDDLE HINGE COVER ARCP1 | 1 | 10 | Meer info | |||
| 4524500001 | 197 | TRENCHING PART | 1 | 1 | Meer info | |||
| 4902980100 | 210 | FOAMED DOOR ASSY_B220_SLIDING | 0 | 1 | Meer info | |||
| 4652880200 | 216 | Charging tube II New 100 mm Drept | 0 | 1 | Meer info | |||
| 4528400200 | 216 | CHARGING TUBE II | 6 | 0 | Meer info | |||
| 4838490100 | 218 | EGG TRAY (NTT_OPAC ARC-P1) | 2 | 1 | Meer info | |||
| 4089670200 | 250 | HINGE BUSHING | 1 | 4 | Meer info | |||
| 4150052200 | 252 | UPPER DOOR GASKET ASS_Y-SLOT IN (220_230 | 15 | 1 | Meer info | |||
| 4206770200 | 255 | 55 MM DOOR SHELF(54 CM) | 10 | 2 | Meer info | |||
| 4227831500 | 279 | DECORATIVE SEALING | 9 | 1 | Meer info | |||
| 4210300100 | 280 | RIGHT FRONT FOOT | 4 | 1 | Meer info | |||
| 4210300200 | 280 | LEFT FRONT FOOT | 3 | 1 | Meer info | |||
| 4237950100 | 311 | CRISPER (B-220_230 SMALL NATUREL) | 17 | 2 | Meer info | |||
| 5525230700 | 371 | COVER COMPRESSOR | 5 | 0 | Meer info | |||
| 4249370100 | 401 | LAMP_THERMOSTAT HOUSING | 7 | 1 | Meer info | |||
| 4241520100 | 403 | DULIE LAMPA | 4 | 1 | Meer info | |||
| 5760500100 | 404 | LED BULB | 13 | 0 | Meer info | |||
| 4249380100 | 406 | LAMP_TERMOSTAT HOUSING GLASS (LINE 2001) | 3 | 1 | Meer info | |||
| 4528340100 | 416 | SERVICE TUBE III (NEW) | 6 | 0 | Meer info | |||
| 4841080600 | 511 | CRISPER COVER EDGE PROFILE | 2 | 1 | Meer info | |||
| 4541850100 | 716 | COMPRESSOR SUPPORT (NEW)/ 54CM | 13 | 1 | Meer info | |||
| 4206430100 | 838 | 100 MM DOOR SHELF(54 CM) | 12 | 1 | Meer info | |||
| 4812690100 | 864 | WINE HOLDER (DIFFUSION) | 8 | 1 | Meer info | |||
| 4209390100 | 1010 | TOP CONNECTING PLASTIC | 9 | 1 | Meer info | |||
| 4303496500 | 1107 | 55 MM DOOR SHELF ASS.(54 CM _ BEKO) | 16 | 1 | Meer info | |||
| 4617500200 | 1651 | GLAS SHELF BACK COVER 54CM 2010 WO_I | 7 | 4 | Meer info | |||
| 5635400601 | 1668 | TERMINAL ASSY. | 21 | 0 | Meer info | |||
| 5635411401 | 1669 | ANLASSER KPL.MTS85MT-104KFBYY-2,5MF-ARYL | 13 | 0 | Meer info | |||
| 4617490200 | 1850 | GLAS SHELF FRONT COVER 54CM 2010 WO_I | 8 | 4 | Meer info | |||
| 4629840700 | 2185 | GLASS SH. 415X264 SAFETY GLASS (LEFT) | 15 | 4 | Meer info | |||
| 4629860700 | 2188 | CRISPER COVER 445X265 SAFETY GLASS LEFT | 14 | 1 | Meer info | |||
| 4629850700 | 2196 | GLASS SH ASS 415X264 SAFETY GLASS (LEFT) | 18 | 4 | Meer info | |||
| 4322510100 | 2197 | PLASTIC | 11 | 1 | Meer info | |||
| 5226221241 | 2199 | COMPRESSOR MTS85MT(220-240V)(+evap tray) | 42 | 0 | Meer info | |||
| 4307640500 | 2312 | FURNITURE CONNECTION PARTS | 17 | 1 | Meer info | |||
| 4622784800 | 2476 | EQUIPPED SUPPLY CORD_TU_TG_1110Y (AL) | 18 | 1 | Meer info | |||
| 4543619200 | 2477 | EQ. SUPPLY CORD MTS 85 MT | 23 | 0 | Meer info | |||
| 4502020001 | 3070 | 2-WAYS DRYER | 10 | 1 | Meer info | |||
| 4505150101 | 8538 | MOTORCOMPRESSOR FIXING PART. | 1 | 2 | Meer info |
